Aluminium Camlock Coupling D Type

Name: Aluminium Camlock Coupling D Type
Brand: SHREE SAMARTH ENTERPRISES
Price: 140.0 INR
Availability: InStock

Price 140.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Aluminium Camlock Coupling D Type Specification

Max. Speed
Static device, not rated for rotary speed.

Torque
Hand tightened, cam arms provide mechanical locking-no torque rating required.

Sealing
Nitrile, Viton, or EPDM gasket seals.

Thread
BSP or NPT threads available.

Connection
Female threaded end (BSP/NPT) with camlock coupling.

Bore
Full bore design to minimize flow resistance.

Head Code
Round

Material
Aluminium alloy, usually A356 or equivalent.

Structure
Cam arm locking design, dust cap compatible.

Standard
MIL-C-27487 / EN 14420-7

Inner Diameter
1/2 to 6 (DN15 - DN150) as per model.

Outer Diameter
Varies by size, corresponds to inner diameter.

Application
Quick hose connection and disconnection in industries such as petrochemical, chemical, agriculture, and water transport.

Surface Treatment
Anodized or sandblasted for corrosion resistance.

Technique
Precision die-casting.

Shape
Female coupler with locking arms (Type D).

Cam Arm Material
Stainless steel for enhanced durability.

Gasket Options
Buna-N, Viton, EPDM.

Pressure Rating
Up to 250 psi (17 bar), size dependent.

Corrosion Resistance
High, suitable for heavy-duty industrial applications.

Maintenance
Low, regular gasket and cam inspection recommended.

Usage
Used for coupling pipes, hoses for fluids, powders, and granules.

Color
Natural aluminum silver.

Weight
Depends on size; 0.2kg to 2.5kg typical range.

Temperature Range
-20C to +100C (depending on gasket material).

Interchangeability
Compatible with other MIL-C-27487 camlock couplings.

About Aluminium Camlock Coupling D Type

Take advantage of the grand capabilities of the Aluminium Camlock Coupling D Type, a trending solution for rapid pipe and hose connections in the most demanding industries. Procure this redoubtable coupler, engineered for superior corrosion resistance, built from precision-cast A356 aluminum alloy. Spectacular in its versatility, the D Type thrives in applications involving fluids, powders, and granules, operating across a temperature range from -20C to +100C. Stainless steel cam arms and premium gasket options provide enhanced durability, while full bore design ensures optimal flow. Compatible with standard camlock systems, this coupling exemplifies reliability with minimal maintenance.

Features & Advantages of Aluminium Camlock Coupling D Type

This camlock coupling is crafted for straightforward application-simply hand-tighten the female threaded end, lock the cam arms, and trust the dust cap compatibility for secure closure. Its grand material feature: high-grade aluminium alloy construction ensures both lightweight handling and spectacular corrosion resistance. The type of usage spans the coupling of hoses and pipes in industrial arenas such as petrochemicals, water transport, and agriculture, fostering efficiency in both fluid and powder transfer.

Sample Availability, Certification, and Payment Terms for Aluminium Camlock Coupling D Type

Procure your sample to assess the arrival of quality; swift handover is guaranteed. Certified under MIL-C-27487 and EN 14420-7 standards, this coupling ensures dependability and compliance. Competitive rates suit diverse procurement needs, and flexible payment terms-including advance, partial, or upon delivery-make acquisition seamless. Expect prompt sample dispatch and thorough documentation to support industrial requirements.

FAQ's of Aluminium Camlock Coupling D Type:

Q: How does the Aluminium Camlock Coupling D Type benefit industrial users?

A: This coupling expedites the connection and disconnection process, saving valuable time during equipment setup and maintenance. Its corrosion resistance and compatibility with industry standards ensure long-lasting, dependable service.

Q: What is the process for installing the D Type Camlock Coupling?

A: Installation involves aligning the female coupler with a male adapter, engaging the locking arms by hand, and ensuring the gasket is correctly seated for a secure, leak-free seal.

Q: When should regular maintenance or inspection be performed on the coupling?

A: Regular maintenance includes periodic inspection of the cam arms and gaskets, especially before and after intensive operating periods, to ensure optimal performance and safety.

Q: Where can the Aluminium Camlock Coupling D Type be utilized?

A: This coupling is widely used in petrochemical plants, water transport systems, agricultural irrigation, and chemical handling industries for efficient pipe and hose connections.

Q: What gasket materials are available, and how do they impact temperature range?

A: Gasket options include Buna-N, Viton, and EPDM, each offering distinct resistance to temperature and media. Choice of gasket determines the safe operating temperature range, from -20C up to +100C.

Q: How is the coupling rated for pressure, and does it vary by size?

A: The Camlock D Type is rated for up to 250 psi (17 bar), although actual pressure limits depend on the selected size and gasket material, ensuring adaptability to various industrial pressures.
